AbusiveAlcoholic

Car started missing and knocking, pining, or rattling. diagnosed as " done for " So my plan was to buy a new ( used ) motor. but 1st wanted to know why this motor died..

cornholio

iTrader: (1)

precats disentegrated sucked back into the motor scored cylinder walls car drank oil ran dry kaboom.

maximatech12

This can happen??

Itz Shak

Yes, you're not the first. Too bad you didn't know sooner.

cornholio

iTrader: (1)

it's a 3.5 problem. our tiny dek engines were spared this fate

that's why you see so many people saying "gut your precats" or "get headers" for the 5.5 gen

Child_uv_KoRn

iTrader: (7)

5.7 swap or go home

nestorlugo

iTrader: (11)

We should have a meme by now!!! You sleeping brah!!!

AbusiveAlcoholic

2,4,6 ( front ) ring end gaps were rather large.. Id say in the spectrum of .200" to .220" range.. Compared to the factory spectrum as being .0091" to .0374" as per Chilton! 1,3,5 ( rear ) I never had one in the cylinder but there end gaps looked waaaaaay better pinched on the piston..But the number 5 lower ring or middle ring was broke

AbusiveAlcoholic

Engine Came out easy since i had to replace the radiator core support awhile back due to the typical front engine mount rust away..

AbusiveAlcoholic

see how thin the # two ring is in spots.. and the 246 cylinder walls were worn down .008" of an inch

AbusiveAlcoholic

split the case

Child_uv_KoRn

iTrader: (7)

AbusiveAlcoholic

Cylinders bored .020 over and crank just needed to be polished.. the heads just needed a good cleaning, so the head guy said.. he resurfaced it as well

AbusiveAlcoholic

Not sure i should have blasted the engine but i wanted to go big!

AbusiveAlcoholic

Primed




Painted

VQ35maxima=Beast

iTrader: (1)

Lookin good!

AbusiveAlcoholic

want to see what they looked like slapped together

AbusiveAlcoholic

Thanks Beast
