Post your engine bay pics here!! All gens welcome

This hasn't been done in a while, so I figured I'd kick off a new thread. I'm hoping that this thread will inspire us and give us ideas on what our next mod will be.

Here are the rules:
1. Post one pic of your engine bay (ok ok...3 pics maximum).

2. No neglected, nasty, rusty, ratty engine bay pics allowed.

3. No "work in progress" engine bay shots with the engine removed.

3. Pics should be clear and not blurry (no cel phone or night time pics please)

4. Must have at least 2 mods easily distinguishable in picture(s).

5. If your engine bay is completely stock, it better be hella clean, shiny, glossy, and free of rust. So clean that I could eat off of it.

6. No BS and worthless chit chatting which doesn't contribute to the thread. Compliments are fine.

7. If someone post 3 pictures, and you want to talk about 1 picture, please don't quote ALL 3 Pictures...this will keep the repetitiveness and scrolling to a minimum.

8. If you don't like what you see, either stay quiet or offer constructive criticism. Don't be a d1ck about it.

Optional: Provide a brief list of only your mods related to the engine/engine bay (what we see in your picture(s))

GO!!



First (I'll post up a pic after i detail my engine again w/ my AE cover, thats just the shot after i did my valve cover gaskets and wrinkled my valve covers)

DE-k



New pics to come soon with wrinkle red valve cover.



And Wiz, how can you start this thread and not post pics of your epic engine bay?





Visible mods : battery relocated, custom CAI, Racingline strut bar, painted engine covers, wireless control boxes for custom lighting



:sigh:





Full 00vi (with 00 airbox and snorkel)

Simple and clean



Looks good .. How do u like the kinetix UIM?



cleaned up the bay 3 weeks ago



Way to get things going phatboi! Nice!! Looking forward to your revised pics. Be sure to show a closeup shot of your wrinkled valve cover(s).

Tigershark: Good pic dude. Nice valve cover. I'll post up mine soon enough.

Greeny: I knew I should have specified "Maximas only" You win.

Ghozt: Great pic. Nice mods too. Looks like a clean install on that custom CAI. Your color choice appears to be "Superman" red.

blackonblack: Oooooh yeah...bring it. What BOV is that? Does it bolt right up to the original flange on the Stillen charge pipe? or custom?

hero: That looks good! I spy nice personal touches everywhere (ie fender washers). That reminds me, I gotta install mine!

danmack: Clean install. Looks like it came from the factory.

JonBlz: Nice and glossy.



My engine bay... Im trying to get my buddy totry and do a semi wire tuck, but its such a huge job... Has anyone pulled off a Wire tuck?



yea, but he eventually put things back to stock because it was more of a pain..i'm sure you can successfully do it though. just takes time and patience

thanks wiz i have a few other 'clean ups' i personally want to do and ill get another shot



Mods:
VQ35HR
Nismo sticker on FTSB (Atleast 10+ whp!)

2nd pic:
Grocery Getter Mod (took it from the Max before I traded her in)
Didja know, the 350z has a "Safety Child Latch?"



I have one mod that is not visible (SS clutch line) but hey at least my engine bay is in show room condition so you can eat off of it !!!





my old 4th



^ drool



Exactly what I was going for! It took a little extra time but I got the box and snorkle to work perfect. Stock box ftw



2006 Mustang GT:


engine bay mod list:
stock manifold with Ford Blue Duplicor Engine Enamel with Ceramic
C&L Intake elbow and cone filter
GT500 take-off strut tower brace
1995 VQ35 Maxima SE (goodnight sweet prince...):



engine bay modlist:
2002 3.5 swap
polished 3.0 timing cover
NWP spacers and VIAS block-plate
blue 02 intake manifold (same paint as above)
3.0 stock intake system mated to pathfinder throttlebody (not shown)
AEM Fuel Pressure Regulator
Sorry guys, this is the best picture I have since the car was rear ended by some dude a few days later. This swap was so clean looking.


I like blue intake manifolds in red cars, obviously!!!



I love it, I felt really good gains on top end!



Giddy Up.



this looks awesome excellent job



^^^^^ stupid clean. Looks like everything is brand new



waahhh-psshhh



I love the sleek look on some of these. Very clean.



Modified Intake location, Battery relocated slightly, 6th gen engine cover, custom modified radiator hold downs, stainless hardware everywhere... Blah Blah Blah





Very nice! Here's my engine bay pic:



Basic Mods:
VQ35DE Engine Swap in a 92 Maxima with full ECU wiring from 02 Maxima
NWP Engineering Thermal Intake Spacers and VIAS Block Plate Kit
SSIM
And tons more!

For a full list of modifications and more details, please visit:
http://www.nwpengineering.com/maxima.html



I'm in. Stainless steel, powder-coat, titanium and lots of elbow grease. It's pretty.





Thanks Aaron, the products your company sells are legit. I plan to buy a 5.5 gen as a daily driver in the future so my mustang doesn't get beat up too bad in my commute, I'll be buying some go fast bits again from you.



Thank you for all your support!



WINNAR!!!!!!!!!!!!!!!!!!
Super clean, and with nice visible mods.



^^^yeah that looks good, Requin



here is one of my old car. mods were mid pipe, FPR, SPW strut tower bar, and a hidden nitrous system



Dirty *** bay..



Thank you sir. I'm sure yours doesn't look too bad either.



vote for this one
my dream engine bay



would you tell us how to clean engine bay to looks like yours?
(sorry for my bad english)



There are a few things that would go into cleaning an engine bay to look like that.

1. you would need a good cleaner like simple green or purple power
2. a steam cleaner would also come in handy
3. assorted brushes for scrubbing
3b. a lot of rags
4. something to shine the plastics, such as tire shine.
5. a low pressure hose to rinse with



*ahem* Where's the OP's pics?
